Description

SOL21024C7000 AIGNEP
SOL21 024 C 7 000 AIGNEP
Nominal voltage (DC): 24 V
Resistance at: 20 °C 30 Ohm
Current at nominal voltage: 0.8 A
Power / electrical consumption: 22 W (at 24 V and 0.8 A)
Coil length / height: 36-38,50 mm
Outer diameter: 48 mm
Mounting hole (inner diameter): 13 mm
Connector / connection: Deutsch 3-pole connector
Cewka
Magnetspule
Solenoid coil
Solenoide spoel
Electromagnetic coil
Bobina del solenoide
Bobine de solénoide
Bobina de solenoide
Mágnesszelep tekercs
